Ford Transit Custom (05/2016+) Brake Light Reversing Camera kit with 7" Mirror Display - PM39BLH
Description
About the Ford Transit Custom brake light reversing camera with 7 inch mirror monitor kitWhen somebody wants a reversing camera for a van, the most popular option these days is a brake light reversing camera. This is because of the following reasons:
The reversing camera installed in this brake light camera has a ball design that has a very small adjustment up/down using a friction lock mechanism, it should be noted that this doesn't allow it to be angled to face upwards enough to view down the road as a driving camera. What vehicle does this fit?Ford Transit Custom with LED brake light May 2016+ Mirror Monitor Mounting OptionsWe stock a number of different mounting options for the mirror monitor, depending on what you currently have fitted to your van. Kindly note that if you choose any mount other than the clip-over original mirror, and your van has a plastic trim cover that hides the metal mirror mount button, this will need to be removed and likely won't fit back once the bracket is fixed in position - although we have been told that this isn't too much of an issue since the mirror monitor mostly hides this anyway. Clip over original mirrorThis type of mirror monitor has spring loaded clips on the rear, instead of 4 screw holes for our swan neck brackets to fit. Ideal if you have a van with an interior mirror already fitted. ACCMB2 - Fit to original Ford windscreen buttonThis is the most commonly seen windscreen button fitted to various Ford vans. We have had customers with Transit customs who have told us they have had to remove plastic trim, and if they have auto wipe windscreen wipers, they have had to remove a plastic bracket that sits on top of the regular metal button shown in the image below. The plastic trim may need trimming or removing, the good news is that this is not easily noticeable once the new mirror monitor is in position. ACCMB2 + Button + Glue - Adds a new Ford windscreen button to vans without oneIf you have no metal windscreen button to attach our bracket to, then you can add your own. This option provides the Ford windscreen stalk, plus the Ford windscreen button, as well as the Loctite 319 glue. Please see our instructions on how to glue a mirror button to the windscreen. Download our PDF fitting instructions for fitting the windscreen button with Loctite 319 mirror button adhesive. Choice of kit power options
Easy-Fit Wiring
Image Sensor for CameraThis particular system uses the PC4089 1/3" Hi-Res CMOS image sensor (not to be confused with the older technology low res CMOS), this runs at 700TVL and gives a really crisp picture with a good colour replication. We use 4xglass composite lens instead of the cheaper 2xglass, 2xplastic lenses, which cloud/fade over time due to UV exposure. With our camera you can be assured of good performance and long term reliability. 2 Year GuaranteeWe supply with a 2 year Guarantee with us, meaning we will repair or replace any non-user damaged parts that are deemed faulty. Our failure rate is very low even beyond these two years, if you have a problem outside of 2 years we should still have compatible parts and possible repairs for reasonable amounts. Parts Tested in the UKThe parts of this kit will have been tested twice, once by the factory and once by us. We check all the items in the kit including all cables, trigger wires, IR leds and menu functions to reduce any chance of having a non working part. Our fault rate is extremely low, and we just like to ensure that we avoid any imperfection slipping past. This is why professional fitters love us. |
Detailed Images
Picture of brake light camera mounted
Advice if you have an aftermarket spoiler
Monitor Dimensions
Wiring Layout (monitor side) - clip-on mirror version shown, if using monitor with swan neck bracket the cables may looks slightly different
Choice of power options suchas lighter plug and piggyback fuse holder taps
Yes you can, the monitor powers the camera, this means you can choose to watch the camera at any point, you can drive with it "always on". It is worth noting that the camera faces downwards, so it may not be used as a rear view driving camera.
Our easy wire fuse tap options are new for 2023. We designed a fuse tap that plugs in to a socket that is present on all of our monitor wiring harnesses. The other side has a "piggyback" fuse holder aka fuse tap. You identify a fuse in the fuse box that comes on/off with the ignition (see piggyback fuse holder / fuse tap instructions here - PDF download). The original fuse is placed in to the new fuse tap, plus there is a new fuse already present for the reverse camera kit. On the same wiring there is an earth terminal connector, simply attach this to a chassis bolt (usually near the fuse box, or add your own).
Yes, absolutely. You can also choose to hard wire it at a later point. Some people order the lighter plug option simply to try it out before they wire it in permanently.
Yes it does. The camera outputs its own fixed guidelines (these can be turned off by snipping a small loop of wire that is next to the cameras connector). The monitor can also add guidelines itself, these will only be shown if you connect up the green reverse trigger wire on the monitor wiring. The advantage of using the monitors guideline function instead of the cameras is that you can adjust the position on the monitors guidelines (see the instructions tab for the downloadable PDF on how to do this).
Our guide to the menu system and monitor. Covers the adjustable guidelines that can be added when reverse gear is connected to the green trigger wire on monitor wiring harness.
Monitor7” Diagonally Measured Colour LCD screen CameraSensor: 1/3" PC4089 CMOS |
