Peugeot Expert/Traveller, Vauxhall Vivaro, Toyota Proace 2016-present Brake Light Reversing Camera | CAM340

Category: Brake Light Reversing Cameras

Printable Version

Gallery Ask a question about this product

Description

About the Peugeot Expert/Traveller, Vauxhall Vivaro, Toyota Proace brake light reversing camera

This brake light reversing camera is ideal for the vans listed, to add a reversing camera where the existing brake light is located.
The image sensor we have installed is one of the latest generation 700TVL premium CMOS, which gives a really nice clear picture.
The camera has the 4 pin plug on it's fly lead.
The camera is waterproof up to IP69K.

What vehicle does this fit?

Peugeot Expert 2016-Present

Peugeot Traveller 2019-Present

Vauxhall Vivaro 2019-Present

Toyota Proace 2016-Present

Image Sensor for Camera

This particular system uses a 700TVL image sensor and gives a really crisp picture with a good colour replication. With our camera you can be assured of good performance and long term reliability.

Detailed Images

Reversing camera for Peugeot Expert/Traveller, Vauxhall Vivaro, and Toyota ProAce

Thanks to RFT Automotive for the picture of the brake light camera installed on his Vauxhall combo

Instructions

Fitting a 4 pin reverse camera - including using adaptors to RCA/Phono

Download

See our general guide to installing 4 pin reversing cameras. This includes fitting to stereos inc Kenwood / Sony / Pioneer etc.

Fitting guide for 4 pin reversing cameras including to stereo headunits

Technical Specs

Image Sensor : 1/3" colour Super CMOS
Effective Pixels : 976(H) x 592(V)
Resolution : 700TVL
Minimum illuminations : 0.1 Lux (day)
Lens Angle : 170 degrees
Waterproof : IP69K
AGC : Auto
Signal to noise ratio : Better than 48dB
White balance : Auto
Electronic Shutter : Auto
Power Supply : DC12V
Operating Temperature : -20C to 70C RH95% MAX
Storage Temperature : -40C to 80C RH95% MAX
